The Bevles PHC44-16INS-A-1R1 Proofing and Holding Cabinet Insulated
Why Use Bevles Proofing Cabinet?
BevLes Combination Holding & Proofing cabinets are all aluminum construction and are available in insulated and non-insulated models. Universal extruded pan supports accommodate a wide variety of pans and screens while see-through Lexan doors with heavy-duty hinges feature positive closing latches and full perimeter gaskets.User-friendly, bottom-mounted controls feature independent heat and humidity adjustment. Temperatures range from 80° to 180°F (27° to 82°C) and the water reservoir holds up to 5 quarts (4.7 liters). Bevles "cast-in" humidity system prevents element burnout while providing added safety for the operator. All BevLes proofing and holding cabinets have a self-draining feature for excess moisture collection below the cabinet base into a standard 18"x26" bun pan - pan not included. Heavy-duty swivel-type plate casters with 5" (127mm.) rubber wheels, two with locks, provided.
Bevles PHC44-16INS-A-1R1 Features
- Self-draining feature collects excess moisture into a standard bun pan (not included) below the base of the cabinet
- "Cast-in" humidity system prevents element burnout from water spills and potential injury from accidental contact with exposed heating element
- All aluminum construction
- Insulated top, sides and back
- Extruded pan supports accept a variety of pans and screens
- Removable heating module with separate controls for heat and humidity
- Maintains uniform temperature and humidity throughout cabinet
- Temperature adjustable from 60°F (15.6°C) to 180°F (82.2°C)
- Completely removable interior components for quick and easy cleaning
- Heavy-duty plate-type casters with 5" hardneoprene wheels, front two with brakes
- 120V, 20A, 1PH service
Bevles PHC44-16INS-A-1R1 Specifications
Cabinet, Casters and Electrical
- Body: .063 Formed aluminum
- 1.50" Thick insulation Top, back, and sides
- Door: Clear Lexan® with an extruded aluminum frame
- Door Latch and Hinges: Positive action door latch with heavy-duty stainless steel hinges
- Door Gasket: Closed cell foam
- Base: .125 Formed aluminum
- Rear (Air Duct) Panel: .063 Formed aluminum
- 20 Amp Switch, and pilot light
- Pan Supports: Aluminum pan supports adjustable on 1.50"centers
- Cord and Plug: 8' cord with 20A molded plug (NEMA 5-20); 208/230 volt models provided with cord only
- Heavy-duty plate type casters, with 5" hard neoprene wheels; all swivel, with wheel brakes on front two casters
Heating Module and Controls
- Bottom mounted heating unit with a one (1) piece modular drop-in design blower assembly, easily removable for maintenance and cleaning
- Air heating element rated at 1600watts
- Humidity heating element rated at 400 watts
- 5 quart (4.7 liter) cast waterreservoir
- Lexan® water reservoir cover
- Easy to operate controls feature digital thermostat, variable humidity control and LED display
- All controls are visible and operable from exterior of cabinet
Bevles PHC44-16INS-A-1R1 Options and Accessories
- Door hinging
- Solid doors
- Dutch doors (2)
- Corner bumpers of gray non-marking vinyl (set of 4)
- Additional extruded universal pan supports
- Perimeter bumper of gray non-marking vinyl
- 6" stainless steel legs with adjustable feet for stationary floor installation*
- 3" casters with hard neoprene or polyurethane wheels
- 18" x 26" chrome electroplated wire racks
- Cord Guide/Protector: Unique cord guide provides safe and easy routing to rear of cabinet
* Note: Modifications involving casters or legs may affect the height of the equipment. Specifications subject to change without notice
