Name: Connerton RLRB-23-47L-S 47" Countertop Gas Lava Rock Charbroiler w/ (4) Burners, 112.000 BTU
Brand: Connerton
SKU: CTN-RLRB-23-47L-S
Price: 1511.57 USD
Availability: OutOfStock

The Connerton RLRB-23-47L-S Lava Rock Broiler

Why use Connerton Lava Rock Broiler?

RLRB/L-S series radiant broilers feature 28,000 BTU cast-iron “H” burners. The fully welded #304 stainless steel body and stainless firebox is available in width sizes 12″ through 52″. It is also available as a floor model with adjustable leveling feet or casters.

Connerton RLRB-23-47L-S Features

Stainless steel body
Welded #304 Stainless Steel: For easy cleaning and long life
Removable Fire Box: For easy cleaning and maintenance
Extended Burners - 18” length:For better heat distribution
Fully-welded
28,000 BTU burners
CSA & NSF design certified
23” Deep Body

Connerton RLRB-23-47L-S Specifications

Body: 18 Gauge #304 Stainless Steel, Fully Welded
Fire Box: 16 Gauge #304 Stainless Steel, Welded to Body
Front: Removable 18 Gauge #304 Stainless Steel Panel
Top Grates: Heavy Duty Cast Iron, Adjustable Rear Height
Bottom Grates: Cast Iron
Burners: 28,000 BTU Cast Iron, 18” Long
Drip Pan: 18 Gauge #304 Stainless Steel
Valves: Heavy Duty Brass
Gas Inlet: ¾ NPT
Gas Pressure: 4.0” Natural, 11.0” Propane (Inches Water Column)
Legs (Floor Model): 1-1/2” sq. X 16 Gauge #304 Stainless Steel tubing welded to

Connerton RLRB-23-47L-S Options

1/2” Steel Rolling Rod Grates
Stainless Steel Plate Shelf
4” Legs Accessory

From The Manufacturer

Charbroiler, countertop, gas, 47"W, lava-rock with cast iron bottom grates, cast iron top grates with rear height adjustment, manual controls, 3/4" NPT rear gas connection, fully welded stainless steel body, fire box, front & drip pan, 112,000 BTU, NSF, CSA

Manufacturer	Connerton
Model Number	RLRB-23-47L-S
Weight	295 lbs
Depth	23″
Height	13″
Width	47″
Control Type	manual controls
Installation Type	countertop
Number of Burners	4 burners
Power Type	gas
Heating Source	lava rocks
Certifications	NSF
Total BTU	112,000
Cooking Surface Depth	21"
Heating Source Material	cast iron
