High‑Velocity Grease Fan for Restaurant Ventilation
The GSV400 delivers powerful, variable‑speed airflow to maintain negative pressure and clear grease‑laden air from kitchen ducts, boosting safety and compliance.
Key Features
- Three‑phase 1HP motor, 1720 RPM, 3x208‑240 V, 3x400 V
- Cast aluminum housing, 3/16" thick, grey hammer‑paint finish, IP54 protection
- Variable speed with thermal overload protection and sealed ball bearings
- Maximum discharge velocity 4,134 FPM, 1.03×CFM at 3x400 V
- ETL‑listed (File No. 514733), CE compliant, 2‑year factory warranty
From The Manufacturer
Enervex Grease Fan, 3x208-240/3x400, 1720 RPM, 1HP (UL762), Item No: 133.1000.1200 - The GSV is part of a mechanical draft fan for intended use as part of a restaurant kitchen exhaust system and grease application. Ensures a negative pressure in the entire duct or vent system. Discharges vertically (horizontally, if side-wall mounted) at a high velocity. The fan housing is hinged and the top can be opened for easy service and access to stack. The GSV model is approved for temperatures up to 575°F (300°C). Exhaust fan for installation at the duct or vent termination point, vertical or side-wall mounted.
GSV 200-250-315: Single phase, split capacitor, totally enclosed, Class F insulated, IP54 Protection Class. Sealed ball bearings. Variable Speed. Thermal overload protection.
GSV 400-450: Three phase totally enclosed TEFC motor, Class H insulated. Sealed ball bearings. Variable Speed. Thermal overload protection.
The GSV 200-450 Grease Fan is ETL Listed in the U.S. and Canada under File No: 514733
