Wolf AGM SERIES MANUAL CONTROL HEAVY-DUTY GAS GRIDDLE
SPECIFICATIONS
Low profile heavy duty gas griddle, Wolf AGM Series Stainless steel front, sides and front top ledge. Fully welded stainless and aluminized steel body frame. 11" low profile cooking height on 4" legs. 1" thick polished steel griddle plate with 12 gage, 4" stainless steel back and tapered side splashes. Grease chute is fully welded to stop grease migration. One 27,000 BTU/hr. “U” shaped aluminized steel burner for every 12" of griddle width. One high range infinite heat control valve per burner. 3 ½" wide stainless steel grease trough. ¾" rear gas connection and pressure regulator.
Exterior Dimensions:
- AGM24: 24"w x 24"d griddle plate "w x 31 1⁄2" d x 15 1⁄2" h on 4" legs.
- AGM36: 36"w x 24"d griddle plate"w x 31 1⁄2" d x 15 1⁄2" h on 4" legs.
- AGM48: 48"w x 24"d griddle plate"w x 31 1⁄2" d x 15 1⁄2" h on 4" legs.
- AGM60: 60"w x 24"d griddle plate"w x 31 1⁄2" d x 15 1⁄2" h on 4" legs.
- AGM72: 72"w x 24"d griddle plate"w x 31 1⁄2" d x 15 1⁄2" h on 4" legs.
STANDARD FEATURES
- Stainless steel front, sides and front top ledge with “Cool Bullnose” design
- Fully welded stainless and aluminized steel chassis frame.
- 11" low profile cooking height on 4" adjustable legs.
- 1" thick polished steel griddle plate with 12 gage, 4" stainless steel back and tapered side splashes.
- Spatula wide 31⁄2" grease gutter and grease chute is fully welded for easier cleaning and to stop grease migration.
- One 27,000 BTU/hr. “U” shaped aluminized steel burner for every 12” of griddle width.
- Large 6 quart stainless steel grease drawer (2 drawers on 60" and 72" models).
- One high range infinite heat control valve per burner
- Bottom heat shields.
- Standing pilot ignition system
- One year limited parts and labor warranty.
From The Manufacturer
Heavy Duty Griddle, countertop, gas, 72" W x 24 "D cooking surface, 1" thick polished steel griddle plate, (6) burners, 4" back & tapered side splashes, manual controls, (2) 6 quarts grease drawer, stainless & aluminized steel chassis frame, 11-1/8" low profile cooking height on 4" adjustable legs, 162,000 BTU, cCSAus, NSF
