Imperial IHR-GT36-M 36" Gas Heavy Duty Range, 36" Full Girddle w/ Thermostatic Controls, Modular,90.000 BTU

Imperial IHR-GT36-M Features

Open Burners

• Anti-clogging burner is 21% more efficient than other manufacturers’ heavy duty burners.
• 35,000 BTU/hr. (10 KW) output with a 7,000 BTU/hr. (2 KW) low simmer feature.
• One-piece venturi base has no gaskets.
• Venturi slopes down to the burner creating more efficient heating.
• Cast-iron burners remove and separate for cleaning.
• All stainless steel pilot tubing and solid brass top burner valves for a long service life

Grates

• Wavy grates create more heat transfer. Heat convects in waves for continual heat-to-pan contact
• Grates measure 12" x 14" (305 x 356 mm) and 18" x 14" (457 x 356 mm) depending on model.
• Cast-iron design features flame shaping center tube for more efficient heat transfer.
• Anti-clogging shield designed into the grate protects the pilot from grease and debris.

Hot and French Tops

• Heavy duty, highly polished plates provide even heat across entire hot top surface.
• 12” Hot Top is rated 30,000 BTU/hr. (9 KW) output and 18” Hot Top is rated 40,000 BTU/hr.(12 KW) output.
• Burners are located every 12" (305 mm) or 18" (457 mm). Each burner has one manual control.
• “U” shaped burners have aeration baffles between burners for quick recovery.
• Circular cast iron rings and lift off covers. Rings located directly over the burners.
• Pans can be placed directly on the intense open flame when covers are removed.
• One cast iron ring burner rated 35,000 BTU/hr. (10 KW) for 18" (457 mm) section, IHR-2FT models and 36" (914 mm) section, IHR-1FT models.
• Temperatures gradually reduce toward the rear of each top for simmering.
• Heavy duty tops measure 18" w x 28" d (457 w x 711 d mm), IHR-2FT models and 36" w x 28" d (914 w x 711 d mm) IHR-1FT models.
• Tops have cast-in heat retaining projections underneath to absorb and defuse heat.
• Each burner has one adjustable gas valve and one standing pilot. Manual controls for each burner.

Griddle Tops

• Highly polished griddle plate provide even heat across entire surface.
• 12” Griddle is rated 30,000 BTU/hr. (9 KW) output and 18” Griddle is rated 40,000 BTU/hr. (12 KW) output.
• Burners are located every 12" (305 mm) or 18" (457 mm). Each burner has one manual control.
• “U” shaped burners have aeration baffles between burners for quick recovery.
• Manual or thermostatic (GT36) controls are available.
• 4" (102 mm) wide grease gutter and large grease can with 1 gallon (3.8 L) capacity.
