FWE ETC-UA-6PH Height Mobile Heated Holding Proofing Cabinet

General Informations

FWE's heavy-duty ETC-UA-PH Series hold 18" x 26", 12" x 20", 14" x 18", 12" x 18", 20" x 22", 10" x 20" as well as Gastro-Norm sizes: GN 2/1, GN 1/1 and GN Maxi-Pans. Cabinets are insulated on the left wall and door for greater heat retention than NON-insulated cabinets.

Construction

Stainless Steel / Non Insulated - Constructed of stainless steel, with welded base frame for added strength and durability.

Control Panel

Mechanical Controls
Proofer Controls - Easy to use - upfront and recessed electronic control panel has separate, easy to read and set, air moisture and air temperature controls.

Heat System

Proofer Heat System - Proofer and amplified moisture heated holding. Built-in humidity system balances moisture and air with controlled heat and humidity capabilities - allows for greater control of holding food environment for longer holding period.

Slides and Shelves

Adjustable Universal Slides Stainless Steel - Unique universal design holds 12" x 20" pans, 18" x 26" sheet trays or GN containers on fully adjustable stainless steel tray slides. Slides are removable for thorough interior cleaning.

FWE ETC-UA-6PH Specifications

OVERALL EXTERIOR DIMENSIONS IN. (mm) : 43.25″ (1099) H X 30,5" (775) D X 29,25" (743) W
NUMBER OF DOORS : 1
CASTER SIZE : 5"
SHIP WT. LBS.(KG) : 240 (109)
OTHER DETAILS : See Spec. Sheet

From The Manufacturer

Proofer/Heater Cabinet, mobile, (6) pair universal tray slides, (6) 18" x 26" or (12) 12" x 20" tray capacity, 4-1/2" OC, adjustable on 1-1/2" increments, humidified proofer/heating system, adjustable thermostat, separate controls, non-insulated cabinet, (1) insulated door, recessed hand grip, removable water reservoir, stainless steel interior & exterior, 5" casters (2) rigid & (2) swivel with brakes, UL, cUL, NSF

Manufacturer	FWE
Model Number	ETC-UA-6PH
Weight	240 lbs
Width	29.25″
Depth	30.5″
Height	43.25″
Control Location	bottom
Slide Spacing (in)	1-1/2"
Installation Type	mobile
Cabinet Size	half height
Door Type	solid door
Insulation	non-insulated
Exterior Finish	stainless steel exterior
Interior Finish	stainless steel interior
