Southbend 24" Sectional Range Full-Width Electric Griddle

Standard Features

24" wide sectional electric range with full-width griddle available with a cabinet base, or as a modular unit (for mounting on countertop, refrigerated or freezer base).
Two 5.3 kW heating elements with two control knobs
1/2" thick griddle plate with side and rear splashers
9-1/4" deep front rail
Removable stainless steel grease drawer
Stainless steel front, sides, rear and exterior bottom
Fully insulated lining and burner box
5" high stainless steel flue riser
Free battery-design assistance
(1) year limited parts and labor warranty.

Standard Features of Cabinet-Base Models

Stainless steel cabinet with removable doors that open from the center

WARRANTY & SERVICE REQUEST

“Do you need service? Is your product under warranty? Please fill out the form at the link below.”

Warranty & Service Request Form

From The Manufacturer

Platinum Heavy Duty Range, electric, 24", modular, (1) 24" x 24" (10.6 kW) griddle, thermostatic controls, front rail, stainless steel construction, 6" adjustable legs, cCSAus, NSF

Manufacturer	Southbend
Model Number	PE24N-TT
Weight	250 lbs
Width	24″
Depth	37.5″
Height	13.5″
Range Type	heavy duty/modular range
Base Type	modular unit/model
Top Configuration	griddle
Exterior Finish	stainless steel front & sides
Top	(1) griddle
Voltage	208, 240, 480
Wattage	10.6 kW

	Southbend PE24N-TT Platinum Heavy Duty Range, Electric, 24", Modular Free Shipping	Southbend PE24C-TT Platinum Heavy Duty Range, Electric, 24" Free Shipping	Southbend PE12N-T Platinum Heavy Duty Range, Electric, 12", Modular Free Shipping	Southbend PE36N-TTT Platinum Heavy Duty Range, Electric, 36", Modular Free Shipping	Southbend PE24N-HH Platinum Heavy Duty Range, Electric, 24", Modular Free Shipping	Southbend PE24N-BB Platinum Heavy Duty Range, Electric, 24", Modular Free Shipping	Imperial IHR-GT36-E-M Spec Series Heavy Duty Range, Electric, 36", Modular Free Shipping	Southbend PE12C-T Platinum Heavy Duty Range, Electric, 12" Free Shipping	Southbend PE36C-TTT Platinum Heavy Duty Range, Electric, 36" Free Shipping
Price	Price	Price	Price	Price	Price	Price	Price	Price	Price
Shipping	ShippingFree Shipping	ShippingFree Shipping	ShippingFree Shipping	ShippingFree Shipping	ShippingFree Shipping	ShippingFree Shipping	ShippingFree Shipping	ShippingFree Shipping	ShippingFree Shipping
Wattage	Wattage10 - 19 kilowatts	Wattage10 - 19 kilowatts	Wattage0 - 9 kilowatts	Wattage10 - 19 kilowatts	Wattage10 - 19 kilowatts	Wattage10 - 19 kilowatts	Wattage10 - 19 kilowatts	Wattage0 - 9 kilowatts	Wattage10 - 19 kilowatts
Voltage	Voltage208, 240, 480	Voltage208, 240, 480	Voltage208, 240, 480	Voltage208, 240, 480	Voltage208, 240, 480	Voltage208, 240, 480	Voltage208, 240, 480	Voltage208, 240, 480	Voltage208, 240, 480
WIDTH (SIDE - SIDE)	WIDTH (SIDE - SIDE)24	WIDTH (SIDE - SIDE)24	WIDTH (SIDE - SIDE)12	WIDTH (SIDE - SIDE)36	WIDTH (SIDE - SIDE)24	WIDTH (SIDE - SIDE)24	WIDTH (SIDE - SIDE)36	WIDTH (SIDE - SIDE)12	WIDTH (SIDE - SIDE)36
Manufacturer	ManufacturerSouthbend	ManufacturerSouthbend	ManufacturerSouthbend	ManufacturerSouthbend	ManufacturerSouthbend	ManufacturerSouthbend	ManufacturerImperial	ManufacturerSouthbend	ManufacturerSouthbend
Top	Top(1) griddle	Top(1) griddle	Top(1) griddle	Top(1) griddle	Top(2) hotplates	Top(4) round hotplates	Top(1) griddle	Top(1) griddle	Top(1) griddle
Base Type	Base Typemodular unit/model	Base Typecabinet/storage base	Base Typemodular unit/model	Base Typemodular unit/model	Base Typemodular unit/model	Base Typemodular unit/model	Base Typemodular unit/model	Base Typecabinet/storage base	Base Typecabinet/storage base
Exterior Finish	Exterior Finishstainless steel front & sides	Exterior Finishstainless steel front & sides	Exterior Finishstainless steel front & sides	Exterior Finishall stainless steel exterior	Exterior Finishstainless steel front & sides	Exterior Finishstainless steel front & sides	Exterior Finishstainless steel front & sides	Exterior Finishstainless steel front & sides	Exterior Finishall stainless steel exterior
Vent	Ventbackriser with hi-shelf	Ventbackriser with hi-shelf	Ventbackriser with hi-shelf	Ventbackriser with hi-shelf	Ventbackriser with hi-shelf	Ventbackriser with hi-shelf	Ventbackriser	Ventbackriser with hi-shelf	Ventbackriser with hi-shelf
Width	Width24"	Width24"	Width12"	Width36"	Width24"	Width24"	Width36"	Width12"	Width36"
Top Configuration	Top Configurationgriddle	Top Configurationgriddle	Top Configurationgriddle	Top Configurationgriddle	Top Configurationhot top	Top Configurationfrench top	Top Configurationgriddle	Top Configurationgriddle	Top Configurationgriddle
Range Type	Range Typeheavy duty/modular range	Range Typeheavy duty/modular range	Range Typeheavy duty/modular range	Range Typeheavy duty/modular range	Range Typeheavy duty/modular range	Range Typeheavy duty/modular range	Range Typeheavy duty/modular range	Range Typeheavy duty/modular range	Range Typeheavy duty/modular range
Certifications	Certifications-	Certifications-	Certifications-	Certifications-	Certifications-	CertificationsNSF, cCSAus	Certifications-	Certifications-	Certifications-

Manufacturer	Southbend
Model Number	PE24N-TT
Weight	250 lbs
Width	24″
Depth	37.5″
Height	13.5″
Range Type	heavy duty/modular range
Base Type	modular unit/model
Top Configuration	griddle
Exterior Finish	stainless steel front & sides
Top	(1) griddle
Voltage	208, 240, 480
Wattage	10.6 kW
