The Toastmaster Countertop Gas Griddles are the most economical and flexible Countertop Griddles in the food service industry.
Why use Toastmaster Gas Griddles?
The Toastmaster Countertop Gas Griddles are the most economical and flexible Countertop Griddles in the food service industry. They offer unsurpassed performance, combining a proven control system with Toastmaster quality and durability. Available in three different widths - 24”, 36” and 48”.
Technical Information
Stainless steel front including top rail, with aluminized steel rear and sides, with 4-3/8” high rear and side splash guards and full-width stainless steel grease trough and easy to access grease drawer.Gas units have 5/8” polished rolled steel plate.
Toastmaster TMGM36 Specification
Gas griddles are constructed with a stainless steel front panel and reinforced wall aluminized steel side panels. Griddle plate is 3/4” (1.9 cm) thick steel plate with 4-3/8” (11.1 cm) high tapered wrap-around stainless steel splash guard. Unit has 3-1/4” (8.3 cm) wide front grease trough with grease chute and a 4-1/2 qt. (4.257 L) stainless steel grease drawer. Unit is equipped with a 20,000 BTU aluminized steel burner for every 12” (30.5 cm) of width and is controlled by a either manual control valve or throttling thermostat. Valve knobs are protected by a stainless steel bull nose front. A standing pilot is provided. Griddles are supplied with 4” (10.2 cm) high die cast nickel-plated legs with a 1-3/8” (3.5 cm) adjustment. Gas connection is a 3/4” (1.3 cm) N.P.T. male with a convertible pressure regulator. Units are approved for installation within 6” (15.2 cm) of combustible and non-combustible surfaces and are UL Gas Certified and UL Sanitation listed. Printed in the U.S.A.
Toastmaster TMGM36 Features
- NEW Ultra smooth 3/4” thick polished steel plate.
- 3/4” rear gas connection and universal pressure regulator supplied. Field convertible to LP with orifices included.
- Manual griddle designed with 1/4 turn manual control and standing pilot.
- Thermostat griddles feature throttling thermostat that adjust from 150°- 450°F.
- Available in 24”, 36” and 48” widths.
- High performance 20,000 BTU aluminized steel “U” shape burner every 12”
- Spatula wide 3-1/4” front grease trough and grease chute.
- Stainless steel front panel, bull nose and grease drawer.
- 4” nickel plated steel legs.
