Garland Master Series Even Heat Hot Top Range Attachment

Specifications

Heavy‑duty gas range attachment with storage base, Model M12S‑6. One (1) even‑heat hot top. 12" (305mm) wide x 38" (965mm) deep, including 7-1/2" (191mm) deep stainless steel front rail. Stainless steel front and sides. 22,000 BTU (6.44 kW) total. Natural or propane gas. Also available with modular top, Model M12T-6. Free standing units only available with flanged feet deck fasteners to anchor unit. NOTE: Attachments suppled with casters must be installed with an approved restraining device.

Standard Features

Stainless steel front and sides
Stainless steel door
6" (152mm) chrome steel adjustable legs
7-1/2" (191mm) stainless steel front rail
Extra heavy even hear cast iron top
Stainless steel burner box bottom
Heavy gauge aluminized steel radiation baffle system
22,000 BTU (6.44 kW) “H” burner, controlled by hi-lo valve
Storage base interior of aluminized steel

From The Manufacturer

Master Series Heavy Duty Range, gas, 12", modular, Add-A-Unit, hot top, stainless steel front and sides, 30,000 BTU, CSA Flame, CSA Star, NSF (Garland)

Manufacturer	Garland US Range
Model Number	M12T-6
Weight	110 lbs
Width	12″
Depth	38″
Height	36.38″
Installation Type	countertop
Range Type	heavy duty/modular range
Type	add-a-unit
Top Configuration	hot top
Exterior Finish	stainless steel front & sides
Top	(1) hotplate
Total BTU	22,000
