Garland Master Series Open Burner Range Attachment

Specifacations

Heavy‑duty gas range attachment with storage base, Model M5S. One front‑fired spectro‑heat hot top. 17" (432mm) wide x 38" (965mm) deep, including 7-1/2" (191mm) deep stainless steel front rail. Stainless steel front and sides. 45,000 BTU (13.18 kW) total. Natural or propane gas available. Also available with modular top, suffix T.

Standard Features

Stainless steel front and sides
Stainless steel door on storage base
6" (152mm) chrome steel adj. legs
7-1/2" (191mm) stainless steel front rail
Extra heavy cast iron top sections
Removable cast iron ring; and lid
Stainless steel burner box bottom
Storage base interior of aluminized steel
Heavy gauge aluminized steel radiation baffle system
Three individually controlled jet burners 45,000 BTU (13.18Kw) total

From The Manufacturer

Master Series Heavy Duty Range, gas, 17", Add-A-Unit, front fired hot top, jet burners, removable cast iron ring & lid, storage base, stainless steel front, sides & door, 6" adjustable legs, 45,000 BTU, CSA Flame, CSA Star, NSF (Garland)

Manufacturer	Garland US Range
Model Number	M5S
Weight	230 lbs
Width	17″
Depth	38″
Height	36.38″
Installation Type	free standing
Range Type	heavy duty/modular range
Base Type	cabinet/storage base
Top Configuration	hot top
Exterior Finish	stainless steel front & sides
Top	(1) hotplate
Total BTU	45,000
