Imperial IHR-2-18-XB 18" Gas Heavy Duty Range

$4,751.00
Web Price
Free Shipping
Imperial IHR-2-18-XB 18" Gas Heavy Duty Range
The image above may not exactly represent the product
credit key 0% Interest for 90 Days with
credit key Credit Key
Apply Now
Financing Available
?

Small payments, big returns—view financing details now!

Imperial IHR-2-18-XB Specs
ManufacturerImperial
Model NumberIHR-2-18-XB
Weight354 lbs
Depth38
Height42
Exterior Finishstainless steel front & sides
Width18
Top(2) open burners
Typeadd-a-unit
Installation Typefreestanding
Number of Burners2 burners
Total BTU70,000
Base Typecabinet/storage base
Top Configurationburner
Range Typeheavy duty/modular range
Burner BTU35,000
Description
Reviews

The Imperial IHR-2-18-XB Heavy Duty Ranges Add-A-Unit Floor Models

Imperial IHR-2-18-XB Features

Open Burners

  • Anti-clogging burner is 21% more efficient than other manufacturers’ heavy duty burners.
  • 35,000 BTU/hr. (10 KW) output with a 7,000 BTU/hr. (2 KW) low simmer feature.
  • One-piece venturi base has no gaskets.
  • Venturi slopes down to the burner creating more efficient heating.
  • Cast-iron burners remove and separate for cleaning.
  • All stainless steel pilot tubing and solid brass top burner valves for a long service life

Grates

  • Wavy grates create more heat transfer. Heat convects in waves for continual heat-to-pan contact
  • Grates measure 12" x 14" (305 x 356 mm) and 18" x 14" (457 x 356 mm) depending on model.
  • Cast-iron design features flame shaping center tube for more efficient heat transfer.
  • Anti-clogging shield designed into the grate protects the pilot from grease and debris.

Hot Tops And Add-A-Units

  • Heavy duty, highly polished plates provide even heat across entire hot top surface.
  • 12" (305 mm) unit has one 12" w x 28" d (305 x 711 mm) plate, 18" has one 18" w x 28" d (457 xx 711 mm) plate and 24" (610 mm) unit has two 12" w x 28" d (305 x 711 mm) plates. 12" w x 14" d (305 x 356 mm) is also available.
  • “U” shaped burners have 40,000 (12 KW) BTU output. Aeration baffles between burners for quick recovery
  • Burners are located every 12" (305 mm) for 12" and 24" models and every 18" (457 mm) for 18" model. Each burner has one manual control.
  • Both floor model (-XB) and modular/countertop (-M) styles are available.
  • 12", 18" and 24" (305, 457, and 610 mm) wide models are available
  • Common front landing ledges are available as an option with both styles to create a seamless line-up.
  • Floor model has a an open cabinet base. Modular units are featured on separate specification sheet.

Griddle Tops

  • Highly polished griddle plate provide even heat across entire surface.
  • “U” shaped burners have burners have 30,000 (9 KW) BTU output, located every 12" (305 mm) with one control per burner.
  • Aeration baffles between burners for quick recovery.
  • Manual or thermostatic (GT36) controls are available.
  • 4" (102 mm) wide grease gutter and large grease can with 1 gallon (3.8 L) capacity.

From The Manufacturer

Spec Series Heavy Duty Range, gas, 18", Add-A-Unit, (2) open burners, cast iron "S" grates (standard), open cabinet base, bottom shelf, removable crumb tray. stainless steel front, sides, landing ledge, backguard & kick plate, 6" legs, adjustable feet, 70,000 BTU, cETLus, NSF
