Montague Company 36-14E 36" Gas Heavy Duty Range w/ (2) Open Burners, (1) Hot Top, Open Cabinet Base, 100.000 BTU

Overview

The 36-14E,(2) 18" 30,000 BTU open burners (L), (1) 18" even heat hot top (R), open cabinet base with stainless steel front & 4" flue riser, black sides, black intermediate & bottom shelves, 6" high adjustable stainless steel legs, 100,000 BTU, cETLus, CE.

Open Burner Top

• One 18” wide x 31” deep (457 x 787mm)
• Positioned left
• Heavily ribbed cast iron, surface-ground top grate with:
• Two large-diameter 30,000 BTU/hr lift off star burners with raised ports
• Automatic, standing pilots
• Drip pan positioned under open burnersi

Even Heat Hot

• One 18” wide x 37” deep (457 x 787mm)
• Positioned on right
• Heavy-duty cast iron precision ground plate
• Two cast iron, Even Heat 20,000 BTU/hr burners
• Heat transfer studs cast in plate bottom
• 2” (51mm) side and front flanges isolate heat under plate
• Insulating partition between top sections

Montague Company 36-14E Standard Features

• Choice of countertop unit or free-standing range with base options including modular stand, open cabinet base, or oven
• Angle-iron construction provides exceptional structural strength to stand the test of time
• Stainless-steel front
• Stainless-steel 4″ (10.2cm) flue risers
• Painted surfaces are electrolytic zinc coated for superior corrosion protection and long life
• Designed for quick installation
• Easy to clean

Montague Company 36-14E Specifications

• Base Style/Type : With Cabinet Base
• Burners : 4
• BTU/hr (kW) : 100,000 (29.3)
• Shipping Weight: 430 lbs (195 kg)
• Other Details : See spec. sheet
