T&S Brass B-7212-U01XS3 Open Coated Hose Reel Assembly
General Info
3" concealed wall mount mixing faucet with brass body, chrome plated brass escutcheon, compression cartridges with spring checks, lever handles, 3/8" NPT female inlets, 1/2" NPT in-line check valves with 1/2"NPT female inlets, 12" riser, concealed control valve...
T&S Brass B-7212-U01XS3 Features
- All-in-one system with exposed piping and accessories
- 3” concealed wall mount mixing faucet w/ brass body
- Eterna compression cartridges
- Lever handles w/ color coded indexes
- Mixing faucet, 3/8” NPT female inlets
- (2) 1/2" NPT in-line check valves w/ 1/2" NPT female inlet
- 12” and (2) 22” risers w/ concealed control valve between risers
- 2 3/8” wall bracket
- Continuous pressure vacuum breaker
- 36” flexible water hose connector with stainless steel quick disconnect
- Open epoxy coated hose reel with adjustable hose bumper
- High flow spray valve w/ heat resistant blue handle, swivel & hold down ring
- 3/8” x 15’ heavy-duty non-marking hose rated to 300 PSI
T&S Brass B-7212-U01XS3 Specifications
- Pressure : 20 - 125 psi
- Temperature : 40 F - 140 F
- Flow Rate : 2.79 GPM @ 60 psi
- Other Details : See spec. sheet
From The Manufacturer
Hose Reel Assembly, open, 3/8" x 15 ft. hose with high flow blue spray valve with swivel (EB-0107), 3" concealed wall mount mixing faucet, Eterna compression cartridges, lever handles with color coded indexes, (2) 1/2" NPT in-line check valves, continuous pressure vacuum breaker, 3/8" NPT x 36" flexible water hose connector with stainless steel quick disconnect, ratcheting system, multi-fit bracket & adjustable hose bumper, 2-3/8" wall bracket, 12" & (2) 22" risers (with concealed control valve between risers), metal hose reel, brass faucet body, 3/8" NPT female inlets
