UNOX UX164-14416CRA Reverse Osmosis System

Snapshot

The OptiPure® OP350/16 utilizes Reverse Osmosis (RO) to remove >97% of the Total Dissolved Solids (TDS) from water. Then, a balance of minerals is dissolved into the RO water to provide optimized water with desirable TDS for recommended applications. The system operates at line pressure and can produce up to 350-gallons per day of optimal quality water for applications where TDS reduction or the removal of the majority of hardness minerals is required. This complete system includes integrated pre-filtration with particulate and chlorine reduction, reverse osmosis, and mineral addition, in a space saving, wall-mounted design. Adjustable reject flow control allows precise adjustment of product/reject ratio. A built-in full system bypass valve and sample port assures no service interruption and simplifies routine maintenance. Also included is a 16-gallon atmospheric storage tank (with a submicron air breather) with top-mounted repressurization pump. Hose, tubing and fittings required for installation are included.

System Benefits

Significantly reduces scale and corrosion problems related to high TDS, water hardness and chlorides.
Digital before and after TDS meter for push-button monitoring of membrane performance and optimized water quality.
Integrated mineral-addition cartridge provides TDS needed for conductivity sensors and optimal mineral content for all equipment applications
High-capacity pre-filters take out sediment and chlorine and protects the RO Membrane
Adjustable reject flow control minimizes water use due to seasonal fluctuations in water temperature.
Sample port enables quick and simple system checks and adjustments.
Built-in pressure gauge allows visual monitoring of operating pressure.
Integrated system bypass valve eliminates costly service interruptions and down-time.
All consumables are easy-to-change Qwik-Twist cartridges.

Installation Tips

Feed-water connection to system should be COLD only.
Do not exceed system specifications for temperature and pressure.
Provide a dedicated water line of at least 3/8″ I.D. to the unit for consistent flow and pressure to the system.
Allow 3″ clearance below system for filter cartridge removal and replacement.
Connect filtered water line to steam production connections only. Do not use for condenser water.
Detailed installation, operation and maintenance manual is included with each system.
Mount the unit where it can be easily viewed and accessed.

From The Manufacturer

OP350/16 Reverse Osmosis System with 16‐Gallon atmospheric storage tank, integrated dual/parallel prefilters for particulate & chlorine reduction, Mineral-Addition cartridge, dual‐read digital TDS meter displays RO membrane performance and optimized water quality, built‐in full system bypass valve, adjustable reject flow control, storage tank has top‐mounted variable‐flow repressurization system, sub-micron air breather and low water level pump protection switch, includes: QTPTCR10-1 add on chloramine reduction filter, hose, tubing & fittings required for installation, used with following UNOX single and (double) unit configurations XAVX-16FS-EPR/L; XAVX-16FS-HPR/L; XAVX-16FS-GPR/L; (XAVC-06FS-EPRM/LM x 2); (XAVC-06FS-HPRM/LM x 2); (XAVC-06FS-GPRM/LM x 2); (XAVC-10FS-EPRM/LM-side/side); (XAVC-10FS-GPRM/LM-side/side), *Standard Pentair® Limited Warranty*
