Piper Products DB-5-HF 72" Design Basics Hot Food Table, (5) Sealed Wells

for More Info
Piper Products DB-5-HF 72" Design Basics Hot Food Table, (5) Sealed Wells
The image above may not exactly represent the product
credit key Net 30 or as low as 96.83/mo width
credit key Credit Key
Apply Now
Calculate Estimated Shipping Cost
Financing Available
?

Small payments, big returns—view financing details now!

Piper Products DB-5-HF Specs
ManufacturerPiper Products
Model NumberDB-5-HF
Weight279 lbs
Depth31
Height34
Width72
Total well capacity5 wells
Base Constructionstainless steel
Top Constructionstainless steel
Designopen cabinet base
Overall Width (side - side)67" - 72"
Working Height34"
Installation Typestationary
Well Typesealed well
Power Typeelectric
Voltage120
Phase1
Wattage3750 watts
Control Typeınfinite control
Description
Reviews

Piper Products DB-5-HF Design Basics Hot Food Units

Why use Piper Products Hot Food Units?

Piper’s Design Basics Hot Food Tables are designed to hold and maintain the temperature of hot food for use in meal assembly on tray lines. The Design Basics line is constructed of stainless steel tops, bodies, legs and base. Only Piper's equipment has the advantage of technology and certification. This ensures that your food is kept "out of the DANGER-ZONE." Food spoilage occurs mainly because of rapidly accelerated bacteriological activity within the 40F-140F "DANGER-ZONE." With hot food stays above 140°F longer and cold food is kept below 40°F. Both are key factors in HACCP compliance and the fight against foodborne pathogens.

Piper Products DB-5-HF Standart Features

  • Die stamped 20-gauge stainless steel top
  • 14-gauge stainless steel legs fastened to 20-gauge stainless steel base with 14-gauge aluminized caster channels
  • 20-gauge stainless steel wrapper
  • 20-gauge stainless steel bottom-mounted wells, 6-1/2” deep with coved corners and drains
  • 1” insulation on bottom of wells and 1/4” fiber frax all around
  • 750 watt tubular heating element for each well is individually and infinately controlled
  • Wells can be run wet or dry
  • Heating elements are bottom accessible
  • 18-gauge stainless steel cutting board with 1/2” poly board
  • Adjustable stainless steel bullet legs
  • All units are available in 120, 208 & 240 volts
  • All units available in 208 or 240 volt, single- phase or three-phase
  • Six foot electrical cord and plug
  • One year parts and labor

From The Manufacturer

Design Basics Hot Food Table, 34"x31"x72", (5) sealed wells, wet/dry operation, infinite controlled, individual drains/valves standard, 18 gauge cutting board with 1/2" poly board, 20 gauge stainless steel top & base with 14 gauge adjustable bullet legs, 6 ft. electrical cord & plug, 3750 watts
