The Everest ETRF3 Side Mount Undercounter Dual Temp
Why use Everets Dual Temp?
The Undercounter Side Mount series comes with the multi-functional advantages of the back mount line with added features to enhance user experience. It comes with a robust digital display and control system for precise temperature management. Equipped with the Blizzard R290 system, a fully self-contained and detachable condensing unit which uses natural, environmentally friendly, EPA-compliant R290 refrigerant with zero (0) Ozone Depletion Potential (ODP) and three (3) Global Warming Potential (GWP). Blizzard R290 is easily replaceable and requires no on-site brazing.
The Everest ETRF3 Refrigeration System
- Side mounted, self-contained and retractable condensing unit uses environmentally friendly R404A refrigerant with zero (0) Ozone Depletion Potential (ODP) and EPA compliant R290 refrigerant with zero (0) Ozone Depletion Potential (ODP) and three (3) Global Warming Potential (GWP). R290 condensing units are replaceable and require no on-site brazing
- PSC evaporator fan motors for R404A models. Electronically commutated (ECM) fan motors for R290 models.
- R290 models include full-length air duct system.
- Time-initiated and temperature-terminated auto defrost heater for freezers. Air defrost for refrigerators.
- Large capacity, corrosion-resistant condenser and evaporator coils.
- Self-maintaining, energy-efficient condensate drain pan requires no external drains or electric heaters.
- High performance condenser fan motors ensure efficient compressor ventilation. R290 models use autoreverse condenser fan motors which also support condenser coil cleaning. Refer to owner’s manual for full maintenance instructions.
- Removable and washable condenser coil air filter for R404A models. R290 models do not require condenser coil air filters.
- Pressure relief devices allow smooth access to cabinet interior when re-opening doors.
- Pre-wired and ready to plug, 115V/60Hz/1Ph, NEMA 5-15P.
Cabinet Construction And Doors
- Heavy duty stainless steel interior / exterior with rounded corners for a hazard-free workspace
- Insulated interior wall between refrigerator and freezer compartments.
- 16 gauge, high quality stainless steel worktop.
- Galvanized steel top, bottom and rear.
- 2.5" thick high density polyurethane insulation.
- Four 5" swivel casters with locks on front set
- Heavy duty stainless steel interior / exterior.
- 2.5" thick high density polyurethane insulation.
- Frame heaters prevent exterior moisture build up.
- Self-closing with adjustable torsion system for a positive seal.
- Snap-in magnetic door gasket make cleaning and replacement an easy process.
- High strength, recessed door handles.
- Pre-installed door locks keep your items safe from theft
- Energy efficient silicone coated and shatter-proof LED lighting provides bright, high color illumination with low heat output.
Shelving And Temperature Control
- Two epoxy coated, steel wire shelves per section.
- Height adjustable stainless steel clips.
- Multi-function digital controller with easy to read LED display.
- Factory preset temperature, 35°F for refrigerators and -4°F for freezers. Temperature setting range from 33° F to 54°F for refrigerators and -10°F to 54°F for freezers.
- R290 models include audible overheat protection alarm for compressor and condenser coil.
From The Manufacturer
Undercounter/Worktop Dual Temperature Refrigerator/Freezer Combo, three-section, 71-1/8"W, 14.0 (R) & 9.0 (F) cu. ft. capacity, self-contained side mounted refrigeration, 16 gauge stainless steel worktop, (3) solid hinged self-closing doors (locking), (6) epoxy coated wire shelves, height adjustable clips, digital controls with LED display, auto defrost (freezer), LED interior lighting, stainless steel interior, pressure relief port stainless steel front & sides, galvanized steel bottom & rear, (4) 5" swivel casters (2 locking), 1/2 HP, 115v/60/1-ph, 7.77 amps, cord, NEMA 5-15P, NSF, cETLus, ETL-Sanitation
