Excel Dryer ThinAir® HAND DRYER
CONSTRUCTION:
- All covers will be fastened to a base plate by one chrome plated tamper-proof bolt. The cover shall be composed of: ABS – White polymer with SanaForTM antimicrobial additive. SB – Brushed Stainless Steel.
- Base plate shall be equipped with (3) 7/8" (22 mm) diameter knockouts, one of which is located on the right side and suitable for use with surface conduit.
- All internal parts shall be coated according to Underwriters' Laboratories, Inc. requirements.
- Entire mechanism shall be internally grounded, per UL requirements.
- Accessories (optional) Microban® Antimicrobial Wall Guards: 89W (White), 89B (Black), 89S (Brushed Stainless Steel)
MECHANISM:
- Motor shall be a thermally protected, series commutated, through-flow discharge vacuum motor/blower (~½ hp / high-30,000 rpm, low-20,000 rpm) which provides air velocity of up to 16,000 LFM (linear feet per minute) at the air outlet. Includes a washable metal mesh filter for more reliable performance.
- Heating element (550 W) is constructed of Nichrome wire and mounted inside the blower housing behind air baffle, thereby being vandal resistant. It shall be protected by an automatic resetting thermostat, which shall open whenever air flow is cut off and shall close when flow of air is resumed. It shall produce an air temperature of up to 141°F (61°C) at a 72°F (22°C) ambient room temperature at the outlet and 101°F (38°C) at the hands (4 inches [102 mm] below air outlet).
- Control assembly is activated by an infrared optical sensor located next to the air outlet. The dryer shall operate as long as hands are under the air outlet. Control includes a speed and sound control mechanism, adjustable heat control with High, Medium, Low and Off settings and a filter sensor which is activated should the filter become clogged. There is a 35-second lockout feature if hands are not removed. Sensor equipped with externally visible Red LED light that can flash error codes to assist in troubleshooting.
From The Manufacturer
ThinAir® Hand Dryer, surface-mounted, 14 seconds dry time, automatic sensor activated, adjustable speed & sound controller, 35 second lockout feature, washable pre-filter, red LED light, SanaFor® antimicrobial additive polymer (ABS), white, ADA Compliant, OSHA Approved, Building Green Approved, cULus, CE, RoHs, Made in USA
