With capacities ranging from 40 meals to 200, Carter-Hoffmann Banquet Carters are perfect for any operation, large or small
Why use BB Series Banquet Carts?
Take your service anywhere with Carter-Hoffmann Banquet Carters - the first specifically designed for electrical or canned fuel operation. When using canned fuel, EquaHeat's unique heating system uses the natural physics of heat rising by directing the heat up through precision-engineered baffles for even heat distribution throughout the cabinet. The baffle system eliminates the hot and cold spots that are typical when using canned fuel in traditional banquet carts. Or, turn on the electric heater and the same baffles direct heat down and evenly to each plate shelf. Either way, EquaHeat carts provide equal performance and equal plate capacity.
Carter-Hoffman BB1600 Benefits
Double Wall Stainless Steel Cabinet
Strongest, most durable materials for long life. High density 1” thick fiberglass in walls and door,1 1/2” thick on top for maximum heat retention.
Heavy-Duty Stainless Steel Base Frame
12 gauge caster bolsters with perimeter frame for rugged use and added durability.
6” Diameter Industrial Grade Casters With Polyurethane Tread
Long lasting and easy rolling for maximum load and minimum maintenance. Two swivel and two rigid. Swivel casters fitted with brakes. Mounted to base in offset wheel-ahead pattern for easy rolling over uneven surfaces
Removable Wire Shelves
Welded, duplex nickel-plated with reinforced shelf clips. Sturdy for heavy plate loads and removable for cleaning.
Canned Fuel Drawers
Allow access to canned fuel without opening cabinet door. Safety latches keep drawers securely closed during transport. Canned fuel is set back from the drawer handle to reduce burn hazard. Deflector sheilds above drawers force heat to precision-engineered baffle to evenly distribute heat throughout cabinet.
Completely Welded Turned-In Seam Construction
Adds rigidity to entire cabinet and eliminates raw edges for ease of cleaning and safety.
Wrap-Around Bumper
Full perimeter aluminum bumper with nonmarking gray vinyl insert. Protects cart and facility walls from damage.
High Performance Removable Heater
Blower system for fast heat up, recovery and even heat distribution throughout cabinet. Removable without tools for easy service and cabinet cleaning
Carter-Hoffmann BB1600 Technical Information
Construction
Completely welded double wall cabinet construction with outer cabinet formed and welded to base. All seams turned in to eliminate raw edges.
Cabinet Material
All stainless steel construction; 20 gauge polished exterior and 24 gauge interior.
Casters
6” diameter, industrial grade casters with polyurethane tread. Sealed roller axle bearing and double ball bearing swivel. Zerk grease fittings. Plate mounted and bolted to base in offset “wheel ahead” pattern. Two casters fitted with brakes.
Heating System
Two horizontal full width 1” diameter stainless steel tubular push handles with back-up plates.Mounted to each end of the cabinet. Flush mounted, heavy-duty sliding latch with exclusive grip handle.
Push Handles and Latches
Two horizontal full width stainless steel tubular push handles with back-up plates. Mounted to each end of the cabinet.Flush mounted, heavy-duty sliding latch(es) with exclusive grip handle
Electrical Characteristics and Thermometer
Operates on 120 volts, 60 cycle, single phase, 1500 watts, 13 amps. Ten foot rubber cord with 3 pring grounding plug. NEMA 5-15P plug.
Base Frame
12 gauge stainless steel full depth bolsters with 1”x1” 16 gauge tubular stainless steel perimeter supports welded to bolsters.
Bumper
.Non-marking gray vinyl bumper set in heavy duty 3/16” extruded aluminum frame with reinforced corner "cut-outs"
Insulation
1” thick high density continuous wrap-around type fiberglass insulation with 1 1/2” thickness on top
Door
Welded double stainless steel door. 20 gauge polished exterior and 20 gauge interior. Filled with 1” thick high-density fiberglass insulation.
