PH Series Heated Food Transport Cabinets are designed to hold and transport cooked food warm and ready for serving
Why gentle hot air circulation?
Move your feast with heated carts for bulk foods in pans. Great for transport and holding at buffets and remote serving locations.They are constructed of sanitary stainless steel and feature a bottom-mounted lift-out heating system with dial controls and blower heat for even air flow throughout the cabinet. Transport features include wrap-around bumper, wheel-ahead caster pattern and insulated turned-in seam construction.
Carter-Hoffman PH1810 Benefits
Flush Mounted Sliding Door Latch
Exclusively designed for transport applications. Door remains closed during transport. Flush design protects latch from damage
Completely Welded Turned-In Seam Construction
Outer cabinet formed and welded to base. All seams turned in the eliminate raw edges. Adds rigidity to entire cabinet.
Heavy-Duty Stainless Steel Base Frame
12 gauge caster bosters with 1”x1” stainless steel perimeter channel supports to withstand heavy loads and harsh transport conditions
Non-Marking Gray Vinly Bumper
Set in heavy-duty 3/16” thick extruded aluminum frame with reinforced corner cut-outs. Protects doorways, walls and cart from damage.
Polyurethane Tread Casters With Sealed
Long lasting, easy rolling for maximum load and minimum maintenance.
High Performance Heater
Blower heating system with side mounted interior heat ducts for fast heat up, recovery and even heat distribution throughout cabinet. Removable without tools for easy maintenance and cleaning
Universal Tray/Pan Slides
Heavy-duty stainless steel slides are adjustable on 1- 3/4” centers (standard spacing at 3-1/2”. Accommodate 12”x20” steam table pans, 18”x26” sheet pans, 1/1 and 2/1 gastronorm pans, and 20”x20” glass racks
Offset "Wheel Ahead" Pattern
Only one wheel can pass over uneven surfaces at a time for easy handling and steering.
Carter-Hoffman PH1810 Technical Information
Casters
PH181, PH1810, PH1830, PH1860: 5” and 6” diameter polyurethane tread. All swivel on PH185, PH181, PH1820 and PH1830. Two swivel and two rigid on PH1860. Sealed roller bearing and double ball bearing swivel. Zerk grease fittings. Plated mounted and bolted to base in offset wheel-ahead pattern. Two casters fitted with brakes
Construction
Completely welded cabinet construction and top corners, with outer cabinet formed to base and welded. All seams turned in to eliminate raw edges
Base Frame
12 gauge stainless steel full depth bolsters with 1”x1” 14 gauge stainless steel perimeter tube supports welded to bolsters
Cabinet Material
All stainless steel construction; 20 gauge polished exterior and 24 gauge interior.
Heating System
Bottom-mounted, all stainless steel construction. Removable without tools.1600 watt inconel-sheathed heating element. High impedence protected, internally cooled fan motor. Full range thermostat, remote sensing bulb and power indicating light
Tray Rack Assemblies
16 gauge universal slides, fully adjustable at 1 3/4” spacing, placed into 18 gauge stainless steel rack post. Standard spacing at 3 1/2”.
Doors
Double panel welded stainless steel with heavy-duty vinyl gasket. 20 gauge polished exterior and 24gauge interior. Filled with 1” thick high density fiberglass insulation
Latch
Flush mounted heavy-duty sliding latch for positive closing of door. Easy grip handle bolted to door
Thermometer
Dial type with remote sensing bulb. Located on side of cabinet. Protected by lexan thermometer cover.
Performance
Capable of heating to 200O F (94O C). Preheat to 160O F (71O C) in approximately 25 minutes.
Insulation
High density fiberglass, full 1” thick continuous wrap-around type insulation
Hinges
Concealed, stainless steel hinge with 5/15” pin. 180 degree door swing
Electrical Characteristics
Operates on 120 volts, 60 cycle, single phase, 1650 watts, 13.7 amps. Ten foot 3 wire rubber cord with 3 prong grounding plug. NEMA 5-15P.
