Firex Electric Tilt Braising Pan
General Functional Features
- Heating by means of high efficiency stainless steel tube burners
- Automatic ignition and flame control system without pilot burner
- Temperature control by system with two probes (product/bottom)
- Automatic baskets lifting system by electric engines controlled by electronic card
- Electronic control by means of multifunctional keyboard with Touch Screen 7” and easy and clear messages
- USB connection to download HACCP data, update the software and load cooking programs
- Ability to interrogate the machine using communication protocol MODBUS over RS485 serial interface
Panel Board Functions
- ON/OFF switch
- Resistive 7” touch screen
- Keys for moving basin
- Selection of 2 different cooking modes (4 with optional core probe), with working temperature setting
- Core probe (optional)
- Cooking type and time setting
- Set the cooking time using the basket lifters, with possibility to select automatic lowering when the temperature is reached
- Cooking in “Manual” mode
- Cooking in “Program” mode
- Creating and editing multiphase cooking programs, setting for each phase: type of cooking; cooking parameters (temperature and time), and possibility to insert text messages
- Tank water load setting (hot up to 140° F/cold) with automatic liter measurements
- Control for tilting and return of cooking tank from Touch Screen or keyboard
- Delayed cooking setting with date, time, and programming cycle
- Language settings Touch Screen
- Input of different units of measurement (° C/° F; Liters/gallons; etc)
Display/Signal
- Display type of cooking, temperature probes used and set temperature
- Heating operating visual alarm
- Time to end of cycle display
- Audible/visible warning of automatic basket movements
- Display tank out of position for cooking
- Signaling tap position, managing water in the tank
- Signal of lid and cock position during vat tilting
- Signaling and blocking heat in case there is no gas
- Gas control unit “RESET” message
- Thermostat intervention safety signaling
- Self-diagnostics
Safety System
- Emergency button
- Blocking of heating for excess of temperature with manual resettable safety thermostat
- Heating interruption during vat tilting
From The Manufacturer
Betterpan Tilting Skillet Braising Pan, gas, 58 gallon capacity, programmable electronic controls with 7" touch screen, auto fill, spring-balanced hinged lid, core temperature probe fixed at lid, automatic lifting system, USB connection, adjustable feet, stainless steel construction, 179,000 BTU, IPX4, cETLus, ETL-Sanitation
