Piper Products ACSCA-ST Stainless Steel Cantilever Mobile Cup & Saucer Dispenser

Piper Products ACSCA-ST Specification

• Frame And Body: The frame is constructed of all welded heavy gauge stainless steel. The body is stainless steel on all sides and top, and is fitted with a stainless steel tubular push handle. The front panel is removable for adjustment access.
• Cup Dispensing Mechanism:The rack carrier, constructed of all welded 16 ga. stainless steel, is raised by a series of coil springs attached to the frame. Ball bearing guides and a single stainless steel aircraft type cable keep the carrier level in all directions, even with an unbalanced load. The cable runs over pre-lubricated plated steel pulleys. Adjustment for varying weights is easily accomplished by removing the front panel, then engaging or disengaging individual springs as required.
• Saucer Dispenser: The unit includes two Model AT adjustable, drop-in saucer dispensers (see Page D-9 for specifications). The saucer dispenser size (AT1, AT2 or AT3) is required when ordering
• Casters: The unit is mounted on four 4" diameter, heavy duty, swivel, casters.
