IMC Teddy SFT-1230-SG-ADA Sft Shallow Floor Trough, 30"W X 12"D X 2" Deep

SKU IMC-SFT-1230-SG-ADA

$2,430.00/Each

IMC Teddy SFT-1230-SG-ADA Sft Shallow Floor Trough, 30"W X 12"D X 2" Deep

$2,430.00/Each

0% Interest for 30 Days with

Credit Key

Apply Now

Calculate Estimated Shipping Cost

View Wishlist

View Comparelist

Financing Available

Small payments, big returns—view financing details now!

Information

Usually ships in 2-5 business days

Resources

Spec Sheet

Floor Trough Installation Manual

Seepage Flange Installation Manual

IMC Teddy SFT-1230-SG-ADA Specs

Manufacturer	IMC Teddy
Model Number	SFT-1230-SG-ADA
Weight	58 lbs
Width	30″
Depth	12″
Height	2″
Width (long side)	25" - 36" (3 ft)
Grate Type	subway-style grating
Grate Construction	stainless steel grates
Depth (short side)	12"
Trough Construction	14 ga stainless steel trough
Pan Type	non anti-splash
Deep (pan depth)	2"

View All IMC Teddy Products >

Description

Reviews

Efficient Drainage for High‑Volume Kitchen Floors

Provides rapid, splash‑free floor drainage in tight kitchen spaces, keeping work areas clean and safe.

Key Features

30" W × 12" D × 2" deep trough fabricated from 14‑ga 304 stainless steel for corrosion resistance.
Subway‑style stainless steel grating (SG‑ADA) offers sturdy, easy‑clean surface and secure waste capture.
Integrated recessed flange and 1"‑deep ledge support floor tile installation and grout pocketing.
TIG‑welded joints and brush‑satin finish ensure leak‑proof performance under heavy use.
Non‑anti‑splash pan design directs water directly to the drain, reducing cleanup time.

From The Manufacturer

SFT Shallow Floor Trough, 30"W x 12"D x 2" deep, 14/304 stainless steel, with drain & (SG-ADA) subway grating

Images are for reference. Color, configuration, dimensions and what's included vary by model. See the spec sheet to confirm the exact details.

Compare to Similar ItemsShop All Trough Drains

	IMC Teddy SFT-1230-SG-ADA Sft Shallow Floor Trough, 30"W X 12"D X 2" Deep	IMC Teddy SFT-1236-SG Sft Shallow Floor Trough, 36"W X 12"D X 2" Deep	IMC Teddy SFT-1230-SGAS Sft Shallow Floor Trough, 30"W X 12"D X 2" Deep	IMC Teddy SFT-1236-SG-ADA Sft Shallow Floor Trough, 36"W X 12"D X 2" Deep	IMC Teddy SFT-1230-SG Sft Shallow Floor Trough, 30"W X 12"D X 2" Deep	IMC Teddy SFT-1236-SGAS Sft Shallow Floor Trough, 36"W X 12"D X 2" Deep	IMC Teddy SFT-1272-SG Sft Shallow Floor Trough, 72"W X 12"D X 2" Deep
Price	Price	Price	Price	Price	Price	Price	Price
Shipping	ShippingPlus Shipping	ShippingPlus Shipping	ShippingPlus Shipping	ShippingPlus Shipping	ShippingPlus Shipping	ShippingPlus Shipping	ShippingPlus Shipping
WIDTH (SIDE - SIDE)	WIDTH (SIDE - SIDE)30	WIDTH (SIDE - SIDE)36	WIDTH (SIDE - SIDE)30	WIDTH (SIDE - SIDE)36	WIDTH (SIDE - SIDE)30	WIDTH (SIDE - SIDE)36	WIDTH (SIDE - SIDE)72
Manufacturer	ManufacturerIMC Teddy	ManufacturerIMC Teddy	ManufacturerIMC Teddy	ManufacturerIMC Teddy	ManufacturerIMC Teddy	ManufacturerIMC Teddy	ManufacturerIMC Teddy
Features	Features-	Features-	Featuresanti-slip / non-slip surface	Features-	Features-	Featuresanti-slip / non-slip surface	Features-
Width (long side)	Width (long side)25" - 36" (3 ft)	Width (long side)25" - 36" (3 ft)	Width (long side)25" - 36" (3 ft)	Width (long side)25" - 36" (3 ft)	Width (long side)25" - 36" (3 ft)	Width (long side)25" - 36" (3 ft)	Width (long side)61" - 72" (6 ft)
Grate Type	Grate Typesubway-style grating	Grate Typesubway-style grating	Grate Typesubway-style grating	Grate Typesubway-style grating	Grate Typesubway-style grating	Grate Typesubway-style grating	Grate Typesubway-style grating
Grate Construction	Grate Constructionstainless steel grates	Grate Constructionstainless steel grates	Grate Constructionstainless steel grates	Grate Constructionstainless steel grates	Grate Constructionstainless steel grates	Grate Constructionstainless steel grates	Grate Constructionstainless steel grates
Depth (short side)	Depth (short side)12"	Depth (short side)12"	Depth (short side)12"	Depth (short side)12"	Depth (short side)12"	Depth (short side)12"	Depth (short side)12"
Trough Construction	Trough Construction14 ga stainless steel trough	Trough Construction14 ga stainless steel trough	Trough Construction14 ga stainless steel trough	Trough Construction14 ga stainless steel trough	Trough Construction14 ga stainless steel trough	Trough Construction14 ga stainless steel trough	Trough Construction14 ga stainless steel trough
Pan Type	Pan Typenon anti-splash	Pan Typenon anti-splash	Pan Typenon anti-splash	Pan Typenon anti-splash	Pan Typenon anti-splash	Pan Typenon anti-splash	Pan Typenon anti-splash
Deep (pan depth)	Deep (pan depth)2"	Deep (pan depth)2"	Deep (pan depth)2"	Deep (pan depth)2"	Deep (pan depth)2"	Deep (pan depth)2"	Deep (pan depth)2"
