Vulcan SX24-4BP SX Series Restaurant Range

Vulcan SX24-4BP SX Series Restaurant Range

VUL-SX24-4BP
Details

Vulcan SX24-4BP SX Series Restaurant Range

SKU VUL-SX24-4BP

$2,770.00

Call or Chat Call or Chat


SX Series Restaurant Range, LP gas, 24", (4) 28,000 BTU burners with lift-off burner heads, space saver oven, stainless steel front, sides, backriser & lift-off high shelf, 6" adjustable legs, 142,000 BTU, ETL-Sanitation

Resources

Product PDF

Certifications

ETL-Sanitation

Vulcan SX24-4BP Specs

Brand Vulcan
Model Number SX24-4BP
Weight 358 lbs
Width 23.98"
Depth 32.54"
Height 60.34"
Certifications ETL-Sanitation
Exterior Finish all stainless steel exterior
Top (4) open burners
Base (1) space saver oven
Vent backriser with hi-shelf

Vulcan 24" SX SERIES VALUE RANGE 4 OPEN BURNERS

SPECIFICATIONS

24" wide SX series light-duty range, Vulcan Model No. SX24-4B. Stainless steel front, sides, backriser, high shelf and bullnose. Porcelain door liner and oven bottom. Four 28,000 BTU/hr. cast top burners with lift-off burner heads. Shrouded flash tube pilot system (one pilot per two burners). 12" x 12" cast top grates with aeration bowls. Heavy duty top grates and burner heads. Compression spring door hinge system for durability. 30,000 BTU/hr. oven measures 20.6"w x 25.5"d x 13.7"h. Thermostat adjusts from 250° to 500°F. One oven rack with four rack positions. 3⁄4" rear gas connection and gas pressure regulator. Total input: 132,000 BTH/hr

Exterior Dimensions:

24"w x 32.5"d x 55"h on 6" adjustable legs

  • SX24-4BN: 1 Space Saver Oven / Natural Gas
  • SX24-4BP: 1 Space Saver Oven / Propane

STANDARD FEATURES

  • Stainless steel front, sides, backriser, lift-off high shelf.
  • 6" Stainless steel adjustable legs.
  • 28,000 BTU/hr open top burners with lift-off heads.
  • Shrouded flash tube pilot system (one pilot per two burners).
  • 12" x 12" cast top grates with aeration bowls.
  • 30,000 BTU/hr standard oven cavity measures 20.6"w x 25.5"d x 13.7"h.
  • Oven thermostat adjusts from 250° to 500°F.
  • One oven rack and four rack positions
  • 3⁄4" rear gas connection and gas pressure regulator.
  • One year limited parts and labor warranty.
