CaptiveAire Self-Cleaning Hood
Features and Benefits
- Fully automatic operation
- Hood fabricated from 100% Stainless Steel
- Drip-less nozzles with internal strainer
- Easily serviceable
- Adjustable wash duration (factory set at 3 minutes)
- 3/4", 1", 1.5" NPT Pipe Water Inlet connection
- 1 1/2" NPT Pipe Water Drain connection
- Standard riser spray nozzle for duct cleaning
- Water usage is 0.70 GPM per foot of hood length
- Upgrade to the CORE Fire System available
- High Efficiency Grease Filtration
From The Manufacturer
Hood #1 - H1
5424ND-2-PSP-F - 14ft 0" Long Exhaust-Only Wall Canopy Hood with Front Perforated Supply Plenum with Built-in 3" Back Standoff
Fire System #1 - H1 FS *FINAL HOOK UP, TESTS and PERMITS NOT INCLUDED*
ANSUL-3.0/3.0 Ansul 6 gallon Wall Mounted Fire System (includes pre-piped hood(s) and detection). Includes piping for hood: 1.
Fan #1 DU50HFA - Exhaust Fan (EF1)
NCA16FA Belt Drive Centrifugal Upblast Exhaust Fan with 18.75" wheel
Exhaust Fan handles 3220 CFM @ -1.250" wc ESP, Fan runs at 1175 RPM.
Fan #2 A1-G10 - Supply Fan (SF1)
A1-G10 Direct Drive Direct Drive Untempered Supply Unit with 10" Blower in Size #1 Housing with speed control, disconnect switch.
