The Imperial IHR-2HT-24-M Heavy Duty Ranges Add-A-Unit Modular Models
Imperial IHR-2HT-24-M Features
Open Burners
- Anti-clogging burner is 21% more efficient than other manufacturers’ heavy duty burners.
- 35,000 BTU/hr. (10 KW) output with a 7,000 BTU/hr. (2 KW) low simmer feature.
- One-piece venturi base has no gaskets.
- Venturi slopes down to the burner creating more efficient heating.
- Cast-iron burners remove and separate for cleaning.
- All stainless steel pilot tubing and solid brass top burner valves for a long service life
Grates
- Wavy grates create more heat transfer. Heat convects in waves for continual heat-to-pan contact
- Grates measure 12" x 14" (305 x 356 mm) and 18" x 14" (457 x 356 mm) depending on model.
- Cast-iron design features flame shaping center tube for more efficient heat transfer.
- Anti-clogging shield designed into the grate protects the pilot from grease and debris.
Hot Tops And Add-A-Units
- Heavy duty, highly polished plates provide even heat across entire hot top surface.
- 12" (305 mm) unit has one 12" w x 28" d (305 x 711 mm) plate, 18" has one 18" w x 28" d (457 xx 711 mm) plate and 24" (610 mm) unit has two 12" w x 28" d (305 x 711 mm) plates. 12" w x 14" d (305 x 356 mm) is also available.
- “U” shaped burners have 40,000 (12 KW) BTU output. Aeration baffles between burners for quick recovery
- Burners are located every 12" (305 mm) for 12" and 24" models and every 18" (457 mm) for 18" model. Each burner has one manual control.
- Both floor model (-XB) and modular/countertop (-M) styles are available.
- 12", 18" and 24" (305, 457, and 610 mm) wide models are available
- Common front landing ledges are available as an option with both styles to create a seamless line-up.
- Floor model has a an open cabinet base. Modular units are featured on separate specification sheet.
Griddle Tops
- Highly polished griddle plate provide even heat across entire surface.
- “U” shaped burners have burners have 30,000 (9 KW) BTU output, located every 12" (305 mm) with one control per burner.
- Aeration baffles between burners for quick recovery.
- Manual or thermostatic (GT36) controls are available.
- 4" (102 mm) wide grease gutter and large grease can with 1 gallon (3.8 L) capacity.
From The Manufacturer
Spec Series Heavy Duty Range, gas, 24"W, modular, Add-A-Unit, (2) hot tops, manual controls, removable crumb tray, stainless steel front, sides, 7"D landing ledge & 6"H backguard, 60,000 BTU, 18kW, cETLus, NSF
