The Jade JTKC-48-RAD Chitwood Smoke Broiler
Why Use Jade Titan Series?
Each Titan Heavy-Duty range features a hand-crafted, solid, all-welded frame for incredible strength & durability. All materials used in the production of Jade Titan™ Ranges are chosen to achieve the longest lifespan, allowing Jade Range to offer a 2-year parts and labor warranty within the US & Canada.
Jade JTKC-48-RAD Standart Features
- JTKC-48-RAD: 48" CHARBROILER, RADIANT BURNER
- 14 gauge stainless steel all welded body construction
- Stainless steel front, top rim, stub back and sides
- Heavy duty cast iron grates
- Ceramic briquettes to provide even heat (standard model)
- Cast iron bottom grates for briquette support (standard model)
- One 30,000 BTU/hr. burner every 12" broiler (standard model)
- Cast iron radiant to provide even heat (on "-RAD" model)
- One 15,000 BTU/hr. burner every 6" broiler (on "-RAD" model)
- Variable size multi-point gas connection—see utility information for details
- Infinite control manual gas valves at each burner for precise heat control
- 12 gauge all welded firebox construction
- Exclusive CHITWOOD Smoke-Ejector system to provide maximum smoke to the grill surface. The smoke box is independent of main burner heat for COLD SMOKING
- Two separate 14 gauge steel drip pans to control flare ups
- Stainless steel 6" plate shelf
- Stainless steel cabinet interior and exterior
- Stainless steel gas tubing throughout
- Stainless steel adjustable 6" legs
- 3/4" gas regulator (shipped loose, must be installed for proper operation)
Jade JTKC-48-RAD Specification
CHITWOOD range match “Smoke” charbroiler. To be model #JTKC manufactured by Jade Range. Furnished with 14 gauge all welded body construction and stainless steel front, sides, top rim, stub back and bottom. Provide with heavy duty cast iron grates. One cast iron burner with stainless steel radiants each 12" of broiler. Provide ceramic briquettes for even heat and 12 gauge firebox with all welded construction. Include exclusive Smoke Ejector system, heavy gauge smoke drawer with independent control for cold smoke applications. Furnish two separate 14 gauge drip pans. To have 6" stainless steel adjustable legs.
