The Jade JTRH-5ST Cabinet Base Split Top Range

Why Use Jade Titan Series?

Each Titan Heavy-Duty range features a hand-crafted, solid, all-welded frame for incredible strength & durability. All materials used in the production of Jade Titan™ Ranges are chosen to achieve the longest lifespan, allowing Jade Range to offer a 2-year parts and labor warranty within the US & Canada.

Jade JTRH-5ST Standart Features

JTRH-5ST: 60" five split top section
Individual cast iron top grates with open top front and polished hot top rear
15,000 BTU/hr per hot top section
35,000 BTU/hr per open burner section
Variable size multi-point gas connection—see utility information for details
14 gauge stainless steel all welded body construction
Stainless steel gas tubing throughout
Stainless steel front, sides, tray bed and stub back
Stainless steel 6" plate shelf
3/4" gas regulator (shipped loose, must be installed for proper operation)

Jade JTRH-5ST Specification

Heavy duty cabinet base split top range. To be model # JTRH manufactured by Jade Range. Top sections to consist of cast iron top grates, with open top front and polished top rear. Provide with 30,000 BTU/hr. per open burner section and 15,000 BTU/hr. per hot top section, controlled by infinite gas valves. To have 14 gauge all welded body with stainless steel front, sides, back and bottom. All gas tubing to be stainless steel throughout. To have 6" stainless steel adjustable legs.

From The Manufacturer

Titan™ Heavy Duty Range, gas, 60", (5) 35,000 BTU open front burners, (5) 15,000 BTU rear hot tops, infinite controls, cabinet base, stainless steel 6" plate shelf, front, sides, stub back & bottom, 6" adjustable legs, 250,000 BTU, CSAus, NSF

Manufacturer	Jade
Model Number	JTRH-5ST
Weight	825 lbs
Width	60″
Depth	38″
Height	36.5″
Installation Type	free standing
Range Type	heavy duty/modular range
Number of Burners	5 burners
Base Type	cabinet/storage base
Control Type	manual control
Top Configuration	burner & hot top
Exterior Finish	stainless steel front & sides
Top	(5) open burners front, (5) hot tops rear
Certifications	NSF, CSAus
Total BTU	250,000
Burner BTU	35,000
