Montague Company 36-12E 36" Gas Heavy Duty Range w/ 18" Griddle, (1) Hot Top, Open Cabinet Base, 70.000 BTU

Overview

The 36-12E, (1) 18" griddle (L), 3/4" thick, manual control (1) 18" even heat hot top (R), open cabinet base with stainless steel front & 4" flue riser, black sides, black intermediate & bottom shelves, 6" high adjustable stainless steel legs, 70,000 BTU, cETLus, CE.

Griddle

• One 18” wide x 28” deep (457 x 711mm)
• Positioned left
• 3/4” (19mm) thick precision-ground steel cook surface
• 4” (102mm) high backsplash and tapered side-splashes
• 2-5/8” (67mm) wide grease receptacle trough pitched to grease receptacle
• Built-in 2-1/8” (54mm) hanging grease receptacle
• Two 15,000 BTU/hr gas burners with standing pilots & gas control valves
• Adjusting bolts for changing griddle forward pitch

Even-Heat Hot Top

• One 18” wide x 31” deep (457mm x 787mm)
• Positioned right
• Heavy-duty cast iron precision-ground plate with:
• Two cast iron 20,000 BTU/hr burners
• Heat transfer studs cast in plate bottoms
• 2” (51mm) side and front flanges isolate heat under plates
• Insulating partition between top sections

Montague Company 36-12E Standard Features

• Choice of countertop unit or free-standing range with base options including modular stand, open cabinet base, or oven
• Angle-iron construction provides exceptional structural strength to stand the test of time
• Stainless-steel front
• Stainless-steel 4″ (10.2cm) flue risers
• Painted surfaces are electrolytic zinc coated for superior corrosion protection and long life
• Designed for quick installation
• Easy to clean

Montague Company 36-12E Specifications

• Base Style/Type : With Cabinet Base
• Burners : 4
• BTU/hr (kW) : 70,000 (20.5)
• Shipping Weight: 450 lbs (204 kg)
• Other Details : See spec. sheet
