T&S Brass B-1433-CR-QDS Open Coated Hose Reel Assembly
General Info
8" wall mount mixing faucet with polished chrome plated brass body, ceramic cartridges with check valves, lever handles, 1/2" NPT female inlets, 16" riser, control valve, 40" riser, wall brackets, continuouspressure vacuum breaker, 36" flexible water hose connector with stainless steel quick disconnect, open coated hose reel with 3/8" x 35' heavy-duty non-marking hose...
T&S Brass B-1433-CR-QDS Features
- All-in-one system with exposed piping and accessories
- 8” wall mount mixing faucet w/ polished chrome plated brass body
- Quarter-turn Cerama cartridges with check valves to prevent cross flow of water
- Lever handles w/ color coded indexes
- 1/2" NPT female eccentric inlets with Ø 2" flanges
- Adjustable centers from 7 3/4” to 8 1/4”
- EasyInstall 16” and rigid 40” risers w/ control valve between risers
- (2) 2 3/8” wall brackets
- Continuous pressure vacuum breaker
- 36” flexible water hose connector with stainless steel quick disconnect
- Open epoxy coated hose reel
- 1.15 GPM spray valve w/ heat resistant grey handle and hold down ring
- 3/8” x 35’ heavy-duty non-marking hose rated to 300 PS
- Adjustable hose bumper
- Multi-fit bracket for wall, ceiling or under counter mounting
T&S Brass B-1433-CR-QDS Specifications
- Pressure Min/Max : 20 - 125 psi
- Temperature Min/Max : 40 F - 140 F
- Flow Rate :1.15 GPM @ 60 psi
- Other Details : See spec. sheet
From The Manufacturer
Hose Reel Assembly, open, 3/8" x 35 ft. hose with blue spray valve, 8" wall mount mixing faucet, adjustable centers, quarter-turn Cerama cartridges with check valves, lever handles with color coded indexes, continuous pressure vacuum breaker, EasyInstall 16" and rigid 40" risers, 36" flexible water hose connector with stainless steel quick disconnect, with ratcheting system & adjustable hose bumper, (2) 2-3/8" wall brackets, epoxy coated metal hose reel, 1/2" NPT
