T&S Brass B-0331-VF035-EL Pantry Faucet
General Info
The B-0331-VF035-EL, 8" wall mount mixing faucet with polished chrome plated brass body, 5 3/4" swivel/rigid gooseneck with 0.35 GPM vandal resistant non- aerated spray device, compression cartridges with spring checks, lever handles and1/2" NPT male elbows.
T&S Brass B-0331-VF035-EL Features
- 8” wall mount mixing faucet with polished chrome plated brass body
- 5 3/4” swivel/rigid gooseneck
- Lock washer provided for rigid application
- 0.35 GPM vandal resistant non-aerated spray device, Series 6 (B-0199-06-N035)
- Quarter-turn Eterna compression cartridges w/ spring checks to prevent cross flow of water
- Lever handles w/ color coded indexes
- 1/2" NPT male inlet elbows included
- 1/2” NPT female eccentric inlets w/ Ø2” flanges
- Adjustable centers from 7 3/4” to 8 1/4”
- Material: Polished chrome plated brass body & tubular spout and chrome plated metal handles
T&S Brass B-0331-VF035-EL Specifications
- Pressure Min/Max : 20 - 125 psi
- Temperature Min/Max : 40 F - 140 F
- Flow Rate : 0.35 GPM @ 60 psi
- Other Details : See spec. sheet
From The Manufacturer
Double Pantry Faucet, wall mount, 8" centers, 5-3/4" swivel/rigid gooseneck 0.35 GPM VR outlet, with stream regulator, lever handles with color coded indexes, quarter-turn Eterna cartridges with spring checks, polished chrome plated brass, 1/2" NPT female inlets, installation kit, low lead, cCSAus, ADA Compliant
