The Delfield N8146-NBP Narrow Drop-In Self Contained Mechanically Cooled Refrigerated Cold Pans
Why Use Delfield's Drop-In?
Safety and Sanitation
UL and NSF - All Delfield Drop-in products are UL approved and NSF certified. Which means you can count on safe, consistent construction and performance every time.
Convenience
Delfield Drop-in products are easy to install into any new or existing counter. A press fit flange gasket comes pre-installed making the units ready to drop-in immediately.
Quality
Delfield Drop-in products have an unmatched level of quality. The units are reliably built by the best in the industry and come standard with a 90-day labor and 1-year parts warranty
Construction
Delfield Drop-in products are constructed with stainless steel tops and
interiors. Cold units are insulated with high-density polyurethane foam
and hot units are insulated with fiberglass.
Refrigeration lines are secured to the liner with stainless steel spot
clips and thermal transfer compound is applied to improve heat transferred
cool the food product better.
Delfield N8146-NBP Standart Features
- High density Environmentally friendly, Kyoto Protocol Compliant, Non ODP (Ozone Depletion Potential), Non GWP (Global Warming Potential) polyurethane foam insulation throughout unit
- 2 BF stainless steel interior liner wrapped and spot clipped with refrigeration lines; thermal transfer compound is applied for superior cooling
- N8146-NBP: Two 12” x 20” pan capacity
- Integral V-stamped pan rest
- 20-gauge stainless steel top construction
- Adapter bars are provided standard for 12” x 20” openings
- Standard 1” plastic drain
- Galvanized exterior body
- Non-marring press fit top gasket
- Condensing unit is suspended below on a 16-gauge galvanized frame
- HFC-134A refrigerant
- 8’ cord and plug
- Stainless steel louver provided for field installation
- One year parts and 90 day labor standard warranty
Delfield N8146-NBP Specification
- Top: is one-piece 20-gauge stainless steel. Interior liner is 22-gauge stainless steel and is creased to a 1.00” (2.5cm) diameter drain. Integral V-stamped pan rest recessed 2" (5cm) to accommodate 12” x 20” (30cm x 51cm) pans 4” (10cm) or 6” (15cm) deep supplied by others. Product temperatures of 33°F (1°C) to 41°F (5°C) are maintained at 86°F (29˚C) ambient room temperature, meeting NSF 7 requirements. Adapter bars for 12” x 20” (30cm x 51cm) pans are standard.
- Sides are wrapped with refrigeration lines. Sides and bottom are fully insulated with high-density environmentally friendly, Kyoto Protocol Compliant, Non ODP (Ozone Depletion Potential), Non GWP (Global Warming Potential) closed-cell polyurethane. Exterior housing is 24-gauge galvanized steel.
- Condensing unit is suspended below the cold pan on a 16- gauge steel frame and uses HFC-134a refrigerant. Temperature control has ON/OFF position to shut down cold pan. Unit has an 8’ (2.4m) cord and NEMA 5-15P plug. A stainless steel louver is provided for field installation on the front of the cabinet, 4" below top of counter; cutout dimension for each is 12” x 23.5” (30cm x 60cm).
