Atlas Metal WH-6 Hot Food Drop-In Well Unit, Electric, 6-Pan Size

General Info And Usage Purpose

The WH series hot pan is a versatile, electrically heated drop-in serving unit that can be used as an open bain- marie or with standard 12″ x 20″ steam table pans. The pan construction enables the unit to be used wet or dry. Its stainless steel inner liner is free of all obstructions for ease of cleaning.

Construction

The pan is fully insulated and provided with a factory applied gasket so that it can be installed in the finest wood fixtures, without marring the counter top. All units are furnished with a 3/4″ dia. drain and come in five convenient sizes, to accommodate two to six 12″ x 20″ steam table pans. Adapter bars are available for fractional size pans.

Atlas Metal WH-6 Standard Features

• Fully insulated to retain heat - protects fixtures and saves energy
• Open Bain Marie construction
• Thermostatically controlled
• Factory applied gasket - makes installation a snap and seals units to the counter top, thus eliminating seepage
• Accommodates standard 12” X 20” pans with the use of separator channel(s), or fractional size pans with the use of optional adapter bars
• Wet or Dry Operation
• 1-Year Parts & Labor Warranty
• UL Listed, ETL Listed

Atlas Metal WH-6 Specifications

• WIDHT : 84-3/4” (215.2cm)
• PAN SIZE : 19-7/8” X 80-1/2” X 6” (50.4 X 204.4 X 15.2cm)
• CUT-OUT REQUIRED : 22-1/4” X 83” (56.5 X 210.8cm)
• WATTAGE :850WATT / 1000WATT
• SHIP WT. (LBS.): 227 (102,9kg)
• OTHER DETAILS : See spec. sheet
