Imperial IRF-DS-75 Fryer Dump Station
Imperial IRF-DS-75 Standard Features
- High efficiency cast iron burners have a large heat transfer area.
- Tubes are constructed of heavy gauge metal with a built-in deflector system.
- Millivolt temperature control circuit.
- Snap acting thermostat has a 200° F - 400° F (93° C-204° C) temperature range.
- Fast recovery to desired temperature.
- Heats oil quickly producing a better tasting product with less oil absorption.
- 100% safety shut-off.
- Captures and holds particles below the tubes, out of the fry zone
- Frying area 18" x 18" (457 x 457 mm) for the 75 lb. model.
- Frypot tubes and sides are robotically welded stainless steel to virtually eliminate leaks.
- Fine mesh wire crumb is included.
- Recessed bottom facilitates draining, slants toward the drain.
- 1-1/4" (32 mm) full port drain valve empties frypot quickly and safely.
- Two large, nickel-plated fry baskets with vinyl coated, heat protection handles are included (except IRF-25 and IRF-DS).
- Basket hangers are stainless steel.
- Stainless steel front, door, sides, basket hanger and frypot.
- Welded and polished stainless steel seams.
- Large 5" (127 mm) stainless steel landing ledge to match Restaurant Series ranges.
- Full heat shield protects control panel.
- Full bottom chassis provide structural support.
- Plate mounted 6" (152 mm) heavy duty stainless steel legs or optional casters assures secure support.
- One year parts and labor warranty. Limited warranty on frypot, stainless steel frypot is five years pro-rated.
Imperial IRF-DS-75 Specifications
- OIL CAPACITY : 75 lbs (41 L)
- Dimensions : 19-1/2" w x 38" d x 44-1/8" h (495 x 965 x 1120 mm)
- SHIP WEIGHT Lbs. (Kg) : 270 (122)
From The Manufacturer
Restaurant Series Range Match Fryer Drain Cabinet, 19-1/2", 4"D top drain station, storage cabinet base, stainless steel front, door, sides & drain pan, 6" legs
