Montague Company UFS-60C Gas Underfired Broilers - Ceramic Free Standing Cabinet Base

Overview

The UFS-60C, Legend™ Char-Broiler, 60" heavy duty free-standing, ceramic briquettes, adjustable 3-position cast iron Ultra-Flow reversible top grate, stainless steel front, top trim & splash shields, open cabinet base, 3/4" rear gas, with pressure regulator, 6" adjustable stainless steel legs, 180,000 BTU , CSA Star, CSA Flame.

Burner/Ceramic Bed Features

45,000 BTU/hr cast iron ‘H’ burners
Stainless steel drip shields;
Individual manual gas valves for zoned heat control
Standing pilot for automatic ignition.
Quick heat absorbing ceramic briquettes reduces flare-ups
Full width debris screen under burners and above:
Full width removable trip tray

Montague Company UFS-60C Standard Features

Satin finish stainless steel front & top trim with 4-1/2” (114mm) deep front rail
5-9/16” (141mm) high stainless steel side and rear splash
Open cabinet base with 6” (152mm) adjustable stainless steel legs
Other surfaces painted black with electrolytic zinc undercoating
Full width front grease trough for easy transfer
Removable large capacity grease containe

Montague Company UFS-60C Specifications

Description : Ceramic Style Underfired Broiler Range, Free Standing w/Cabinet Base
Overall Width : 60” (1524mm)
Grates : 8
Cooking Area : 48” x 24” (1219 x 610mm)
Burners : 4
Power BTU/hr (kW) : 180,000 (52.7)
Shipping Weight : 884 lbs (400 kg)
Cube (Crated) ft3/m : 65/1.8
Other Details : See spec. sheet

From The Manufacturer

Legend™ Char-Broiler, 60" heavy duty free-standing, ceramic briquettes, adjustable 3-position cast iron Ultra-Flow reversible top grate, stainless steel front, top trim & splash shields, open cabinet base, 3/4" rear gas, with pressure regulator, 6" adjustable stainless steel legs, 180,000 BTU NSF, CSA Star, CSA Flame

Manufacturer	Montague Company
Model Number	UFS-60C
Weight	1004 lbs
Width	60″
Depth	32.88″
Height	36″
Installation Type	floor model
Power Type	gas
Number of Burners	4 burners
Heating Source	ceramic briquettes
Control Type	manual controls
Base Type	open cabinet base
Exterior Finish	stainless steel front
Grid	flat or tilt, cast iron
Certifications	NSF, CSA Star, CSA Flame
Total BTU	180,000
