Montague Company UFSC-36R Gas Underfired Broilers - Radiant Style Free Standing Countertop
Overview
The UFSC-36R,Legend™ Char-Broiler, 36" free standing, countertop, self-cleaning stainless steel radiants, adjustable 3-position cast iron Ultra-Flow reversible top grate, stainless steel front, top trim & splash shields, 3/4" rear gas, with pressure regulator, 114,000 BTU , CSA Star, CSA Flame, CE.
Burner/Radiant System Features
- 19,000 BTU/hr stainless steel tubular burners
- Individual manual gas valves for zoned heat control
- Standing pilot for automatic ignition
- Heavy-duty stainless steel radiants glow red for infrared broiling
- Removable self-cleaning radiants
- Full width debris screen under burners
- Full width removable drip tray
- Radiants and drip tray heat shields to reduce flare-ups
Montague Company UFSC-36R Standard Features
- Satin finish stainless steel front & top trim with 4-1/2” (114mm) deep front rail
- 5-9/16” (141mm) high stainless steel side and rear splash
- Other surfaces painted black with electrolytic zinc undercoating
- Full width front grease trough for easy transfer
- Removable large capacity grease container
- 3/4” NPT rear gas manifold connection
Montague Company UFSC-36R Specifications
- Description : Radiant Style Broiler Free Standing Countertop
- Overall Width : 36” (914mm)
- Grates : 5
- Cooking Area : 30” x 24” (762 x 610mm)
- Burners : 6
- Power BTU/hr (kW) : 114,000 (33.4)
- Shipping Weight : 392 lbs (178 kg)
- Cube (Crated) ft3/m : 21/.6
- Other Details : See spec. sheet
From The Manufacturer
Legend™ Char-Broiler, 36" free standing, countertop, self-cleaning stainless steel radiants, adjustable 3-position cast iron Ultra-Flow reversible top grate, stainless steel front, top trim & splash shields, 3/4" rear gas, with pressure regulator, 114,000 BTU NSF, CSA Star, CSA Flame, CE
Images are for reference. Color, configuration, dimensions and what's included vary by model. See the spec sheet to confirm the exact details.
