Eagle Group B3CT-18 36" Stainless Steel Underbar Ice Bin w/ 8 Bottle Wells

General Informations

Top, front, backsplash and ice bin to be heavy gauge type 304 stainless steel. Fabricated ice bin is fully insulated, with 1 1⁄2˝ drain and plastic bottle holders. 1 5⁄8˝ O.D. galvanized tubular legs with adjustable bullet feet.

Eagle Group B3CT-18 Features

• Bullnose front edge
• Units are modular, allowing for custom configurations of underbar equipment using standard components.
• 22 gauge type 304 stainless steel front.
• Fabricated ice bin available with ice capacity of 63 lbs. (8˝-deep bin), 94 lbs. (12˝-deep bin), or 125 lbs. (16˝-deep bin).
• Bottom, back panels, and end panels are galvanized steel construction.
• Six- or eight-bottle capacity.
• 1 1⁄2˝ (38mm) drain.
• Adjustable plastic feet
• Post-Mix Cold plates: aluminum casting with seven stainless steel beverage grade tubing circuits. Cold plates are mounted flush with interior bottom of bowl for easy cleaning and maximum efficiency. Drain is 1⁄2˝ (13mm) NPT. 1⁄4˝ (6mm) O.D. tubing beverage connection provided.

Eagle Group B3CT-18 Specifications

• Width x Length in.(mm) : 20˝ x 36˝ (495mm x 914mm)
• Ice Bin Depth in (mm) : 8˝ (203mm)
• Ice Capacity lbs (kg) : 63 (28,6)
• Shipping Weight (lbs.) (kg) : 72 (32,7)
• Other Details : See Spec. Sheet
