Optimized Indoor Walk-In Refrigeration for High-Volume Kitchens
The Astra CMB12X10 provides efficient indoor walk-in cooling and freezing for busy commercial kitchens.
Key Features
- 4" polyurethane panels give R28 (cooler) and R33 (freezer) insulation for lower energy use.
- 24-ga pre-painted white galvanized steel walls and floor deliver durability and easy sanitation.
- Self-closing, keyed-lock doors with optional 120 V heater keep temperatures stable.
- Meets NSF, UL723, DOE, ASTM 518 and ASTM E84 certifications for commercial safety.
- Floor rated 600 lb/ft²; diamond-plate option supports heavy pallet‑jack traffic.
From The Manufacturer
Astra Quick Ship Indoor Walk-In Cooler/Freezer Combination (CMB), both with floor, 11'6"W x 9'10"L x 7'7"H, 4" thick foamed-in-place polyurethane insulation providing R28 for coolers and R33 for freezers, cam-lock panels, tongue and groove design, 24 gauge pre-painted white galvanized steel on interior and exterior surfaces, CFC and HFC free materials, self-closing, flush-mounted doors, keyed locking door handle, 120v/60/1-ph, 1 amp heating wire on freezer doors, pressure relief vent for freezer, NSF, UL, DOE, ASTM Test 518, ASTM Test E84, UL723 Flame Spread and Smoke Development Compliant, 24 gauge pre-painted white galvanized steel panel for floor (same as ceiling panel), optional diamond plate
Images are for reference. Color, configuration, dimensions and what's included vary by model. See the spec sheet to confirm the exact details.
