Garland Master Series Heavy Duty Plancha Style Range Top Option
Specifacations
Heavy‑duty gas range with oven, Model M47R. One 34" (864mm) wide, valve-controlled plancha style perimeter trough griddle plate. 1" (25mm) thick, 99,000 BTU (29 kW) total. 34" (864mm) wide x 38" (965mm) deep, including 7-1/2" (191mm) deep stainless steel front rail. Porcelain enamel oven interior measuring 26-1/4" (667mm) wide x 13-1/2" (343mm) high x 29" (737mm) deep. 40,000 BTU (11.72 kW) cast iron burner. Stainless steel front and sides. 139,000 BTU (40.73 kW) total. Natural or propane gas. Also Available with storage base(s) w/doors, suffix S, and Modular top, suffix T.
Standard Features
- Plancha griddle plate is a 1" (25mm) thick steel griddle plate with side & rear 1"(25mm) wide side perimeter troughs with a 5" (127mm) front trough.
- 2-5/16" (591mm) high welded steel splash guard sides and back
- Stainless steel front and sides
- 6" (152mm) chrome steel adj. legs
- 7-1/2" (191mm) stainless steel front rail
- Clip-on stainless steel backsplash
- Removable front-mounted stainless steel grease receptacle
- Hi-Lo valve control for each griddle burner
- Three “H” griddle burners 99,000 BTU (29 kW) total
- Piezo spark ignition for oven
- Fully porcelainized oven interior
- Storage base interior of aluminized steel w/shelf, (Suffix S)
- Modular top section, (Suffix T)
- 40,000 BTU (11.72kW) natural gas, 35,000 (10.25 kW) propane gas cast iron oven burner
From The Manufacturer
Master Series Heavy Duty Range, gas, 34", modular, griddle, individual Hi-Lo valve controls, stainless steel front and sides, 99,000 BTU, CSA Flame, CSA Star, NSF (Garland)
Images are for reference. Color, configuration, dimensions and what's included vary by model. See the spec sheet to confirm the exact details.
