Vulcan C36IRB 36" HEAVY DUTY GAS INFRARED SALAMANDER BROILER
SPECIFICATIONS
Gas salamander broiler, Vulcan Model No. C36IRB. Stainless steel front, top and sides. Two 15,000 BTU/hr. ceramic infrared burners. 30,000 BTU/hr. total input. Dual heat controls with improved temperature control (250°F-800°F at rack). Pilot ignition system. Cool-to-the-touch knob on lever provides positive positioning of the broiling carriage. Heavy-duty chrome plated broiling grid measures 27 1⁄2"w x 13"d. Removable full width spillage pan. 3⁄4" top gas connection and gas pressure regulator.
Exterior Dimensions:
36"w x 19"d x 17 5⁄8"h (broiler dimensions only). CSA design certified. NSF listed.
SPECIFY TYPE OF GAS WHEN ORDERING. SPECIFY ALTITUDE WHEN ABOVE 2,000 FT.
- C36IRB-N: Natural Gas
- C36IRB-P: Propane Gas
NOTE: C36IRB may be used in conjunction with appropriate reinforced range back riser, wall mounted with optional brackets or counter mounted with optional 4" legs.
STANDARD FEATURES
- Propane Gas
- Stainless steel front, top and sides.
- Dual heat controls for zone cooking.
- Two 15,000 BTU ceramic infrared burners. 30,000 BTU/hr. total input.
- Standing pilot ignition system.
- Cool-to-the-touch knob on lever provide positive positioning of the broiler carriage (6 positions).
- Heavy-duty chrome plated grid (27 1⁄2"w x 13"d).
- Removable full width spillage pan.
- 3⁄4" top gas connection and gas pressure regulator.
- One year parts and labor warranty.
